The Metravi AVD-80 Portable Vibration Meter is a handheld device designed to measure vibration levels in machinery and equipment, allowing users to perform predictive maintenance and fault diagnostics. It helps detect early signs of mechanical issues such as imbalance, misalignment, and bearing faults. This tool is ideal for maintenance engineers, technicians, and industrial professionals who need to monitor machine health and ensure smooth operation. Below are the detailed specifications and features of the Metravi AVD-80:

Key Specifications:

• Model: AVD-80
• Brand: Metravi
• Measurement Parameters: Measures acceleration, velocity, and displacement in industrial machinery.

Measurement Ranges:

• Acceleration: 0.1 - 200 m/s² (RMS or peak)
• Velocity: 0.01 - 200 mm/s (RMS)
• Displacement: 0.001 - 2.0 mm (peak-to-peak)
• Frequency Range:
  • Acceleration: 10Hz to 1kHz
  • Velocity: 10Hz to 1kHz
  • Displacement: 10Hz to 1kHz

Features:

• Digital Display: Large, backlit LCD for easy readability of measurement values, even in low-light environments.
• Data Hold Function: Allows users to freeze readings on the display for easy observation and recording.
• Max/Min Function: Captures and displays the maximum and minimum vibration levels during a measurement session for thorough analysis.
• Auto Power Off: Powers down automatically after a period of inactivity to conserve battery life.
• Sampling Rate: High sampling rate ensures real-time data for accurate vibration monitoring.
• Vibration Sensor: Detachable sensor with a magnetic base for easy placement on measurement points, providing hands-free operation.

Power Source:

• Battery Operated: Uses standard batteries for portability and ease of use in various locations.
• Battery Type: Typically powered by a 9V battery, ensuring extended use before replacement.
• Low Battery Indication: Notifies the user when battery power is low to prevent unexpected shutdowns during measurements.

Safety and Compliance:

• Durable Construction: Designed for use in harsh industrial environments with a rugged, shock-resistant casing.
• Certifications: Meets industry standards for safe and reliable operation of vibration measurement equipment.
• Operating Temperature Range: Suitable for use in diverse environments, from indoor facilities to outdoor inspections.

Physical and Design:

• Compact and Lightweight: Ergonomically designed for easy handling and transport, making it ideal for field use.
• Color: Typically available in a durable, industrial-grade blue or black finish.
• Warranty: One year against manufacturing defects.

Applications:

The Metravi AVD-80 Portable Vibration Meter is suitable for a wide range of applications, including:

• Predictive Maintenance: Monitors vibration levels to predict potential failures and schedule maintenance before a breakdown occurs.
• Condition Monitoring: Provides real-time data to ensure that motors, pumps, fans, and other rotating equipment operate efficiently.
• Fault Diagnosis: Identifies issues such as imbalance, misalignment, looseness, and bearing failures, ensuring prompt corrective action.
• Industrial Machinery: Used across industries like manufacturing, power generation, automotive, and more to ensure optimal equipment performance.
